STE-14
The Saatci Makina STE-14 is a lightweight, mounted-type 4-row planter. The SAATCI MAKINA STE-14 planter is the right choice for a very precise and even planting distance in the field. Furthermore, it offers the possibility of high-speed planting when using well-calibrated seed tubers. The ridge shaping plate ensures that the tubers planted in the soil are evenly covered. Four height-adjustable wheels make it possible to work in very soft soils. It offers convenient seed filling thanks to the tipping hopper.
Standard Equipment
Four-unit chassis
Gradually adjustable motorized belt shaker
Two different sizes of planting belts upon request
Quick-change planting belt locking mechanism
Independent type furrow opener
Ball-bearing and spring-loaded covering discs
Four-wheeled chassis
Tire equipment 7-12
Tipping hopper capacity of 1000 kg
Four-wheeled chassis
| DESCRIPTION / BİLGİLER | SPECIFICATIONS / ÖZELLİKLER |
|---|---|
| Width at 75 cm row spacing | 3700 mm |
| Height | 1860 mm |
| Tipping hopper filling height | 1400 mm |
| Weight | 1685 Kg |
| Weight including ridge forming board | 1050 Kg |
| Empty weight with standard equipment | — |
| Working Width | — |
| Number of rows | 4 |
| Hitch System | Mounted type |
| Hopper / Structure | — |
| Tipping hopper capacity |
|
