STE-34
The Saatci Makina STE-34 is a modular, trailed 4-row planter. It features a special design for the fast and professional planting of large fields. The STE-34 planter is the right choice for a very precise and even planting distance in the field. Furthermore, it offers the possibility of high-speed planting when using well-calibrated seed tubers.
Standard Equipment
Four-unit chassis
Gradually adjustable motorized belt shaker
Two different sizes of planting belts upon request
Quick-change planting belt locking mechanism
Independent type furrow opener
Ball-bearing and spring-loaded covering discs
Four-wheeled chassis
Fast transition from road mode to planting mode via drawbar and chassis
Chassis with two oscillating axles and four-wheel drive
Tire equipment 11.5/8-15.3 IMP
Tipping hopper capacity of 3000 kg
| FEATURE / ÖZELLİK | VALUE / DEĞER |
|---|---|
| Width at 75 cm row spacing | 3290 mm |
| Standard length in planting mode | 5540 mm |
| Filling height of low tipping hopper | 2040 mm |
| Filling height of high tipping hopper | 2840 mm |
| Working Width | |
| Row width | 75 cm |
| Number of rows | 4 |
| Hopper | |
| Capacity of flat tipping hopper | 3000 Kg |
| Tractor Requirement | |
| Without shaping board (min.) | — |
| With shaping board (min.) | — |
| Weight | 2534 Kg |
